SKU:PSV520 (A0294). Obd 2 car code reading card. Engine fault detector elm327 fault scanner
product description
Product material: ABS +
Product size: 171x85x28mm
Commodity weight: 300g
Product color: black
technical parameter
Main control chip: APM32E103VET6, LQFP100
Operating voltage: DC 9V-16V
Operating temperature: -20-60℃
Operating current: 36 mA-54 mA
Standby current: 40 mA
Operating environment: -30-70℃
Storage temperature: -30-70℃
product function:
1. Automobile engine fault diagnosis
2. Automobile engine fault indicator light cleaning
3. Car freezer rack
4.I / M preparation status
5. Vehicle information reading
6. Real-time data flow
7. Vehicle battery voltage reading
8. Mode 6 test
9. Oxygen sensor test
10. Mode 8 test
11. Failure code query
12. Code scanning and printing function
13.35901 fault code library
14. Color screen display is 2.8 inches
Support Agreement:
1.SAE J1850 PWM (41.6 Kbaud)
2.SAE J1850 VPW (10.4 Kbaud)
3.ISO 9141-2 (5 port in., 10.4 gram port)
4.ISO 14230-4 KWP (5 port in, 10.4 poxport)
5.ISO 14230-4 KWP (quick initialization, 10.4K port)
6.ISO15765-4 CAN (11-bit ID, 500 gram-port)
7.ISO15765-4 CAN (29-bit ID, 500 poxport)
8.ISO15765-4 CAN (11-bit ID, 2500 kbaud)
9.ISO15765-4 CAN (29-bit ID, 250 kport)
Supported vehicle data:
1. Read the error diagnostic code
2. Clear error code (clear error code and close MIL)
3. Engine RPM per minute (RPM)
4. Calculate the load value
5. Coolant temperature
6. Fuel oil system status
7. Speed
8. Short-term fuel condition
9. Long-term fuel conditions
10. Intake-air manifold pressure
11. Fuel injection advance time
12. Intake air temperature
13. Air flow rate
14. Absolute position of the throttle valve
15. The relationship between oxygen detection voltage and short-term fuel status
16. Fuel oil system status
17. Fuel oil pressure
18. Fuel consumption monitoring, etc.
Note: The number of supported data items varies from model to year and is influenced by actual support.
Supported languages: English, Germany, Francais, Espano, Italian, Russian, Dutch, Chinese, Japanese, Portugal
Packaging information
Product volume: 24x18x7cm
product size:mm
Packaging size: 200x130x43mm
Product weight: 0.6kg
Binding specifications
40 PC/CTN
CTN SIZE: 54x42x23.5cm
G.W: kg
