14HP 200CC/250CC Vertical Engine Single Cylinder 4-stroke 5-Speed Transmission Motor Kit fit ATV Motorcycles
14HP 200CC/250CC Vertical Engine Single Cylinder 4-stroke 5-Speed Transmission Motor Kit fit ATV Motorcycles
Note: The product you received may be marked 167FML at the bottom, which is the manufacturer's mistake in printing the product is actually 167FMM, 250CC (250cm3 marked on the cylinder block).
Specification
Engine Type: Single Cylinder, 4 Stroke
Material: Aluminium, Cast Steel
Engine Cooling Type: Air Cooling
Ignition System: CDI (Not Included)
Start Mode: Kick-starter; Electric
Clutch Type: Manual Wet Multi-Disc
Transmission:5-speed(Cycle Gear,No reverse gear)
Displacement: 200CC/250CC
Minimum No-load Stable Speed: 1400 (1 ± 10%) R / min
Compression Ratio: 10.0:1
Bore Stroke: 70*64mm/2.75*2.51inch
Max Power: 11.3Kw/h
Max Torque: 18N-m
Max Speed: 7500rpm
Horsepower: 14HP
Air Inlet and Exhaust Valve Clearance: 0.05 ~ 0.07 mm (Cold State)
Min Fuel Consumption: ≤354g/kW.h
Spark Plug: D8TC (Not Included)
Carburetor Type: PZ30 (Not Included)
Primary Reduction Ratio: 4.055
Transmission Ratio of Each Gear: First Gear: 2.909; Second Gear: 1.786; Third Gear: 1.375; Fourth Gear: 1.167; Fifth Gear: 0.900
Lubricant Capacity: 1400ml/0.36 Gallons
Lubricant Type: SL10W/40 (Not Included)
Crankshaft Diameter: 2cm/0.78inch
Crankshaft Length: 1.6cm/0.62inch
Gasoline Type: ≥ 92 #
Gross Weight: 30.85kg/68.01lbs
Net Weight: 28.5kg/62.83lbs
Product Size: 31.5*30.5*43cm/12.4*12*16.92inch
Package Size: 38*36*51cm/14.96*14.17*20.07inch
Package Included
1* ATV Engine
1*Chain Cover
All Accessories for Assembly
Notes
1. Professional installation is highly recommended.
2. Please note that this product is for motorcycles only.
3. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
